Ruban EPR

Lancement de produit de ruban auto-adhésif en caoutchouc éthylène propylène EPR haute pression :

Ethylene-propylene rubber self-adhesive tape is a high-voltage self-fusing EPR rubber insulating tape with good conformability, excellent insulation performance and stability. It can be used for insulation of low-voltage electrical appliances and high-voltage insulation up to 69,000 volts; Has good electrical insulation properties, chemical resistance and temperature resistance.

Paramètres techniques du ruban auto-fusible en caoutchouc :

Résistance à la traction 1.8Mpa

Allongement à la rupture 800 %

Température de surcharge d'urgence 130 degrés

Rigidité diélectrique 32.5KV/mm

Insulation resistance>1 x 106MΩ

Le vieillissement à l'ozone passe

vieillissement par exposition aux rayons UV

Passe de vieillissement de l'exposition au rayonnement de la lampe au xénon

Les données ci-dessus sont des données typiques et non des spécifications de produit.

Utilisation de ruban adhésif en caoutchouc haute tension :

The EPR rubber self-amalgamating tape is easy to use, and each layer of tape in a single roll is protected by a special isolation lining. When the lining is removed, it can be directly half-lapped and spirally wound until it reaches the required thickness. During the winding process, the tape needs to be stretched to 3/4 of the original width. In key positions, the EPR tape can be stretched to the verge of cracking for winding. This will not change its physical and electrical properties. Don't need to stretch that long. When finishing, press the tail for a moment (squeeze it in the direction), and finally wrap 2 circles of PVC adhesive tape on its outer layer as a mechanical protection layer.

Bienvenue à l'e-mailmarketing@senpinghz.com to get offer of EPR high voltage self fusing tape.
